What is Jobstats?

Jobstats is a free and open-source job monitoring platform designed for CPU and GPU clusters that use the Slurm workload manager. It was released in 2023 under the GNU GPL v2 license. Visit the Jobstats GitHub repository.

What are the main benefits of Jobstats over other platforms?

The main advantages of Jobstats are:

  • utilization and memory usage for each allocated GPU
  • automatically cancel jobs with 0% GPU utilization
  • accurate CPU memory usage for jobs of any size
  • graphical interface for inspecting job metrics versus time
  • efficiency reports contain job-specific notes to guide users
  • automated emails to users for instances of underutilization
  • periodic reports on usage and efficiency for users and group leaders
  • all of the above features work with Open OnDemand jobs

How does Jobstats work?

A schematic diagram of the components of the Jobstats platform and the external tools is shown below:

Schematic diagram

A compute node with two sockets is shown in the upper left. The dotted line around the node indicates the three node-level exporters, namely, Node, cgroups and NVIDIA. A GPFS server is shown in the upper right with its cluster-level GPFS exporter. The exporters serve to make data available to the Prometheus database. Users interact with the Prometheus and Slurm data via the web interface (i.e., Grafana) and external tools (e.g., jobstats).

Which institutions are using Jobstats?

Jobstats is used by these institutions:

  • Brown University - Center for Computation and Visualization
  • Free University of Berlin - High-Performance Computing
  • Princeton University - Computer Science Department
  • Princeton University - Research Computing
  • Yale University - Center for Research Computing
  • and more

What does a Jobstats efficiency report look like?

The jobstats command generates a job report:

$ jobstats 39798795

================================================================================
                              Slurm Job Statistics
================================================================================
         Job ID: 39798795
  NetID/Account: aturing/math
       Job Name: sys_logic_ordinals
          State: COMPLETED
          Nodes: 2
      CPU Cores: 48
     CPU Memory: 256GB (5.3GB per CPU-core)
           GPUs: 4
  QOS/Partition: della-gpu/gpu
        Cluster: della
     Start Time: Fri Mar 4, 2022 at 1:56 AM
       Run Time: 18:41:56
     Time Limit: 4-00:00:00

                              Overall Utilization
================================================================================
  CPU utilization  [|||||                                          10%]
  CPU memory usage [|||                                             6%]
  GPU utilization  [||||||||||||||||||||||||||||||||||             68%]
  GPU memory usage [|||||||||||||||||||||||||||||||||              66%]

                              Detailed Utilization
================================================================================
  CPU utilization per node (CPU time used/run time)
      della-i14g2: 1-21:41:20/18-16:46:24 (efficiency=10.2%)
      della-i14g3: 1-18:48:55/18-16:46:24 (efficiency=9.5%)
  Total used/runtime: 3-16:30:16/37-09:32:48, efficiency=9.9%

  CPU memory usage per node - used/allocated
      della-i14g2: 7.9GB/128.0GB (335.5MB/5.3GB per core of 24)
      della-i14g3: 7.8GB/128.0GB (334.6MB/5.3GB per core of 24)
  Total used/allocated: 15.7GB/256.0GB (335.1MB/5.3GB per core of 48)

  GPU utilization per node
      della-i14g2 (GPU 0): 65.7%
      della-i14g2 (GPU 1): 64.5%
      della-i14g3 (GPU 0): 72.9%
      della-i14g3 (GPU 1): 67.5%

  GPU memory usage per node - maximum used/total
      della-i14g2 (GPU 0): 26.5GB/40.0GB (66.2%)
      della-i14g2 (GPU 1): 26.5GB/40.0GB (66.2%)
      della-i14g3 (GPU 0): 26.5GB/40.0GB (66.2%)
      della-i14g3 (GPU 1): 26.5GB/40.0GB (66.2%)

                                     Notes
================================================================================
  * This job only used 6% of the 256GB of total allocated CPU memory. For
    future jobs, please allocate less memory by using a Slurm directive such
    as --mem-per-cpu=1G or --mem=10G. This will reduce your queue times and
    make the resources available to other users. For more info:
      https://researchcomputing.princeton.edu/support/knowledge-base/memory

  * For additional job metrics including metrics plotted against time:
    https://mydella.princeton.edu/pun/sys/jobstats

Which metrics does Jobstats make available?

Job-level metrics:

  • CPU Utilization
  • CPU Memory Utilization
  • GPU Utilization
  • GPU Memory Utilization
  • GPU Power Usage
  • GPU Temperature

Node-level metrics:

  • CPU Percentage Utilization
  • Total Memory Utilization
  • Mean Frequency Over All CPUs
  • NFS Statistics
  • Local Disc R/W
  • GPFS Bandwidth Statistics
  • Local Disc IOPS
  • GPFS Operations per Second Statistics
  • Infiniband Throughput
  • Infiniband Packet Rate
  • Infiniband Errors

The following image shows the Grafana dashboard for an example GPU job:

Other job monitoring platforms

Consider these alternatives to Jobstats:

Want to use Jobstats at your institution?

Proceed to the next section where we illustrate the setup of the platform.
