Expression for constant values (bool, bv, or memory). Constant should be terminating nodes in the AST. More...
#include <expr_const.h>
Public Member Functions | |
| ExprConst (const BoolVal &bool_val) | |
| Constructor for Boolean constant. | |
| ExprConst (const BvVal &bv_val, const int &bit_width) | |
| Constructor for Bitvector constant. | |
| ExprConst (const MemVal &mem_val, const int &addr_width, const int &data_width) | |
| Constructor for Memory constant. | |
| ~ExprConst () | |
| Default destructor. | |
| bool | is_const () const |
| Return true since this is a constant. | |
| z3::expr | GetZ3Expr (z3::context &z3_ctx, const Z3ExprVec &z3expr_vec, const std::string &suffix="") const |
| Return the z3 expression for the node. | |
| std::ostream & | Print (std::ostream &out) const |
| Output to stream. | |
| BoolValPtr | val_bool () const |
| Return the Boolean value. | |
| BvValPtr | val_bv () const |
| Return the Bitvector value. | |
| MemValPtr | val_mem () const |
| Return the Memory value. | |
 Public Member Functions inherited from ilang::Expr | |
| Expr () | |
| Default constructor. | |
| Expr (const std::string &name) | |
| Constructor with name. | |
| virtual | ~Expr () |
| Default destructor. | |
| const SortPtr | sort () const |
| Return the pointer of the sort. | |
| size_t | arg_num () const |
| Retrun the number of argument (arity). | |
| ExprPtr | arg (const size_t &i) const |
| Return the i-th argument. | |
| size_t | param_num () const |
| Return the number of parameters. | |
| int | param (const size_t &i) const |
| Return the i-th paramter. | |
| void | set_sort (const SortPtr sort) |
| Set the sort of the expression. | |
| void | set_args (const ExprPtrVec &args) |
| Set the arguments. | |
| void | set_params (const std::vector< int > params) |
| Set the parameters. | |
| void | replace_arg (const int &idx, const ExprPtr &arg) |
| Replace the i-th argument. | |
| void | replace_arg (const ExprPtr &a, const ExprPtr &b) |
| Replace the "a" argument with "b" argument with "exist". | |
| bool | is_expr () const |
| Is type expr (object). | |
| virtual bool | is_var () const |
| Return true if this is a variable. | |
| virtual bool | is_op () const |
| Return true if this is an operation. | |
| bool | is_bool () const |
| Return true if this is a Boolean expression. | |
| bool | is_bv (const int &width=0) const |
| Return true if this is a Bitvector expression. | |
| bool | is_mem () const |
| Return true if this is an Array expression. | |
| template<class F > | |
| void | DepthFirstVisit (F &func) |
| Templated visitor: visit each node in a depth-first order and apply the function object F on it. | |
| template<class F > | |
| void | DepthFirstVisitPrePost (F &func) |
| Templated visitor: visit each node in a depth-first order and apply the function object F pre/pose on it. | |
| Public Member Functions inherited from ilang::Ast | |
| Ast () | |
| Default constructor. | |
| Ast (const std::string &name) | |
| Constructor with name. | |
| virtual | ~Ast () |
| Default destructor. | |
| bool | is_ast () const |
| Is type Ast. | |
| virtual bool | is_func () const |
| Is type Ast::Func. | |
| InstrLvlAbsPtr | host () const |
| Return the hosting ILA. | |
| void | set_host (const InstrLvlAbsPtr &host) |
| Set the hosting ILA. | |
| Public Member Functions inherited from ilang::Object | |
| Object () | |
| Default constructor. | |
| Object (const std::string &name) | |
| Constructor with string name. | |
| virtual | ~Object () |
| Default destructor. | |
| const Symbol & | name () const |
| Get the symbol (name). | |
| virtual bool | is_instr_lvl_abs () const |
| Is type InstrLvlAbs. | |
| virtual bool | is_instr () const |
| Is type Instr. | |
Additional Inherited Members | |
| Public Types inherited from ilang::Expr | |
| typedef std::shared_ptr< Expr > | ExprPtr |
| Pointer type for normal use of Expr. | |
| typedef std::vector< ExprPtr > | ExprPtrVec |
| Type for storing a set of Expr. | |
| Public Types inherited from ilang::Object | |
| typedef std::shared_ptr< Object > | ObjPtr |
| Pointer type for normal use of Object. | |
| Protected Types inherited from ilang::Expr | |
| typedef std::vector< z3::expr > | Z3ExprVec |
| Vector type for z3 expression. | |
| Protected Types inherited from ilang::Ast | |
|
typedef std::shared_ptr < InstrLvlAbs > | InstrLvlAbsPtr |
| Type for forward declaration of ILA. | |
Expression for constant values (bool, bv, or memory). Constant should be terminating nodes in the AST.
